Hydraulic Axial Piston Pump – V80M series Introduction
Technical Parameter
| Technical Parameter | |||
| Basic type | Displacement cc/rev | Nominal pressure bar | Peak pressure bar |
| V80ML-200 | 202 | 400 | 450 |
Product Features
Variable displacement axial piston pumps adjust the geometric delivery volume from maximum to zero. As a result, they vary the volumetric flow that is provided to the loads. The axial piston pump type V80M is designed for open circuits according to the swash plate principle. It is available with the option of a thru-shaft for operating additional hydraulic pumps in series. The sturdy pump is particularly suitable for continuous operation in challenging applications. The range of pump controllers allows the axial piston pump to be used in a variety of applications.
.With charge pump, higher speed
.High nominal pressure
.Less installation spaces
.Full torque available at the second pump in tandem pump applications
Applications
Coal mining
Concrete pump
Extruder
Industrial plants
Marine cranes and winches
Pile driving machine
Power pack assembly
Presses
Tunnel boring machine
The V80M axial piston pump provides 202 cc/rev displacement, 400 bar nominal pressure, and 450 bar peak pressure. Its variable displacement design optimizes flow for energy efficiency and reliability. Compact and durable, it supports tandem use with thru-shaft operation, making it ideal for coal mining, concrete pumps, marine cranes, winches, and industrial equipment. Built for tough conditions, the V80M ensures consistent high-pressure performance.
